Welcome to Nwabali Aluminium, your trusted partner for premium aluminium solutions right here in Abuja. We take pride in being a leading manufacturer and supplier, dedicated to providing businesses and projects across Nigeria with materials of uncompromising quality. Our Aluminium 2024 Flat Bars are engineered to meet the highest standards, offering the exceptional strength and reliability needed for the most demanding applications, all backed by our commitment to excellent customer service and local expertise.
The composition of Aluminium 2024 is primarily copper, which gives it a distinct advantage in strength. This alloy is part of the duralumin family, known for its excellent strength-to-weight ratio. While it offers impressive mechanical properties, including high tensile strength and good fatigue resistance, it is important to note that its corrosion resistance is lower than that of other series. Therefore, it often requires protective coatings or cladding for use in harsh environments to maintain its integrity over time.
Specification : ASTM B 221 ASME SB 221, B211, B565, B316 1100, AMS 4102
Standard : ASTM, BS and all International Standards
Temper : O, H12, H14, H16, H18, H22, H24, H26, H32, H112
Length : 100 mm To 3000 mm Long & Above
Size : 5 mm To 500 mm
| Aluminium 2024 | Fe | Si | Mg | Mn | Cu | Zn | Ti | Al |
| 0.50 | 0.50 | 1.20 – 1.80 | 0.30 – 0.90 | 3.8 – 4.9 | 0.25 | 0.15 | 93.5 |
| Typical Mechanical Properties (Min) | |||
| Diameter or minor sectional dimension mm | Tensile Strength, MPa | Yield Strength 0.2%, MPa | Elongation % |
| 0-12.7 | 427 | 310 | 10 |
| 12.7-114.30 | 427 | 290 | 10 |
| 114.30-165.1 | 427 | 276 | 10 |
| 165.1-203.2 | 400 | 262 | 10 |
| STANDARD | UNS | WERKSTOFF NR. | European Standard | BS (OLD) | ISO | USA (AA) | GERMANY (DIN) |
| Aluminium 2024 | A92024 | 3.1355 | AW-AlCu4Mg1 | AU4G1 | AlCu4Mg1 | 2024 | AlCuMg2 |
Nwab Aluminium based in Abuja, Nigeria is a renowned manufacturer and supplier of premium aluminium products, including Aluminium Bars, Sheets and Plates, Coils, Chequered Plates, Wires, Pipes, Fittings, Flanges, Forging, Circle, Angles. With a commitment to delivering exceptional quality and service, we cater to diverse industries, offering reliable solutions tailored to specific requirements. Our products are known for their superior strength, corrosion resistance, and precise dimensions. We focus on customer satisfaction by providing an extensive range of aluminium bars designed for structural, industrial, and decorative applications.
Yes, we offer custom sizes for Aluminum 2024 Flat Bars to meet specific project needs. Our team at Nwab Aluminium is committed to providing customized solutions for all your requirements. For more details, contact us at sales@nwabalialuminium.com
The remarkable strength of Aluminium 2024 Flat Bars makes them a go-to choice for high-stress structural applications. You will commonly find them forming the backbone of aircraft components, truck wheels, and various parts in the aerospace industry. Beyond transportation, they are also essential in manufacturing heavy-duty machinery, creating reliable screw machine products, and building robust structural frames where every ounce of strength matters, proving invaluable in sectors that cannot compromise on durability and performance.
Our team is ready to assist you. Contact us for any queries or personalized solutions.
