Nestled in the heart of Abuja, Nwabali Aluminium stands as a trusted partner for industry and construction, priding itself on supplying premium materials like our Aluminium 1050 Chequered Plates. We understand that the right materials are the foundation of any great project. That’s why we ensure our 1050 series plates are sourced with meticulous attention to quality, offering our clients in Abuja and beyond a product that combines strength, durability, and the excellent corrosion resistance that aluminium is known for, all backed by our commitment to reliable service.
The Aluminium 1050 Chequered Plate is crafted from a high-purity alloy, containing at least 99.5% aluminium. This composition gives it outstanding corrosion resistance and makes it highly workable. In terms of strength, it’s a commercially pure aluminium, offering a soft nature with good formability, though it is not known for high strength. It is characterized by excellent thermal and electrical conductivity, and it can be easily welded and shaped, making it a versatile choice for non-structural applications where these properties are more critical than sheer mechanical strength.
Standards : ASTM B209 / ASME SB209
Temper : O,H12,H14,H16,H18,H19,H22,H24
Thickness : 0.2-50
Width : 100-2600
Length : 500-10000
Surface : Bright, polished, hair line, brush, sand blast, embossed, etching, etc.
Finish :Mill, Customer specific finish
Aluminum Chequered Plate Coating : PVC Coated, Color Coated, Polyester, Fluorocarbon, polyurethane and epoxy coating
Type : Hot-Rolled (HR) / Cold-Rolled (CR) Chequered Plate
| European Standard | BS (OLD) | USA (AA) | GERMANY (DIN) | ISO | IS | Canadian |
|---|---|---|---|---|---|---|
| EN AW-1050 A | 1E | 1050 | Al99.5 | Al99.5 | 19500, 19501 | 1 S |
| Alloy (ISS) | Equivalent alloy (A.A) | Copper | Magnesium | Silicon | Iron | Managanese Others* (Total) | Remarks | ||||||||
|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
| Old | New | U.S.A | Min. | Max. | Min. | Max. | Min. | Max. | Min. | Max. | Max | Max. | Aluminum 99.0% Min. | ||
| 1 B | 19500 | 1050 | — | 0.05 | — | — | — | 0.30 | 0.4 | — | 0.05 | 0.1 | Aluminum 99.5% Min. | ||
| Alloy | Temper | UTS (Mpa) | Yield Strength (Mpa) | Elongation (%) | ||
|---|---|---|---|---|---|---|
| Minimum | Maximum | Minimum | Maximum | A 50mm (Minimum) | ||
| EN AW-1050 A | F | 60 | – | 20 | – | 23 |
| O | 60 | 95 | 20 | – | 23 | |
Nwab Aluminium based in Abuja, Nigeria is a renowned manufacturer and supplier of premium aluminium products, including Aluminium Bars, Sheets and Plates, Coils, Chequered Plates, Wires, Pipes, Fittings, Flanges, Forging, Circle, Angles. With a commitment to delivering exceptional quality and service, we cater to diverse industries, offering reliable solutions tailored to specific requirements. Our products are known for their superior strength, corrosion resistance, and precise dimensions. We focus on customer satisfaction by providing an extensive range of aluminium bars designed for structural, industrial, and decorative applications.
Yes, we offer custom sizes for Aluminium 1050 Chequered Plates to meet specific project needs. Our team at Nwab Aluminium is committed to providing customized solutions for all your requirements. For more details, contact us at sales@nwabalialuminium.com
You’ll often find these plates hard at work in bustling industrial settings, serving as durable flooring for walkways, platforms, and factory floors where their chequered pattern provides essential slip resistance. Their natural resistance to rust makes them a favourite for marine applications like boat decks and docks, as well as in architectural features such as decorative panels, truck bodies, and trailers. Essentially, wherever a combination of durability, light weight, and safety underfoot is needed, the 1050 Chequered Plate is a reliable and widely chosen solution.
